Honda Civic IX facelift (2013-2016) grn Wiring diagrams
This page contains all the electrical diagrams for the component. grn, in which he is found in the car Honda Civic IX facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram grn (91 of 168)
A/C COMPRESSOR CLUTCH RELAY
ALTERNATOR
BATTERY
BLK WIRE
BLOWER A/C MOTOR CONDENSER RELAY FAN RELAY
BLU WIRE
D/L LOCK RELAY
D/L UNLOCK D/L DR UNLOCK RELAY RELAY
DRIVER'S POWER SEAT ADJUSTMENT SWITCH (IF EQUIPPED)
ELD
EPS CONTROL UNIT
ETCS CONTROL RELAY
FUSE
FUSE 1 1
FUSE 1-6
FUSE 2-1
FUSE 2-11
FUSE 2-2
FUSE 2-3
FUSE 2-4
FUSE 2-5
FUSE 2-6
FUSE 2-7
FUSE 20
FUSE 23
FUSE 27
FUSE 41
FUSE FUSE
FUSE FUSE 1-3 1-4
FUSE FUSE 2-8 2-10
GRN WIRE
LEFT HEADLIGHT LOW BEAM RELAY
MICU
MOONROOF CONTROL UNIT/MOTOR (IF EQUIPPED)
PGM-FI MAIN RELAY 1
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CONTROL MODULE
RIGHT HEADLIGHT LOW BEAM RELAY
STARTER
STARTER CUT RELAY 1
TAILLIGHT RELAY
TO FRONT ACCESSORY POWER SOCKET RELAY (DIAGRAM 5 OF 6)
TO FUSE 16 (DIAGRAM 2 OF 6)
TO FUSE 26 (DIAGRAM 2 OF 6)
TO FUSE 31 (DIAGRAM 2 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
TO UNDER-DASH SUB-RELAY BOX (DIAGRAM 6 OF 6)
TRUNK RELEASE POWER WINDOW ACTUATOR RELAY RELAY
UNDER- DASH FUSE/ RELAY BOX (UNDER FUSE LEFT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid with keyless access (1 of 6) -> GRN WIRE
Wiring diagram grn (92 of 168)
AUDIO UNIT/ KEYLESS AUDIO- ACCESS NAVIGATION UNIT CONTROL UNIT
AUTOMATIC LIGHTING/ SUNLIGHT SENSOR
AUXILIARY UNDER HOOD RELAY BOX
BATTERY SENSOR
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CEILING FRONT LIGHT INDIVIDUAL MAP LIGHT
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
DATA LINK CONNECTOR (DLC)
DRIVER'S SEAT HEATER RELAY (HIGH) (IF EQUIPPED)
DRIVER'S SEAT HEATER RELAY (LOW) (IF EQUIPPED)
FROM FUSE 11 (DIAGRAM 1 OF 6)
FROM FUSE 13 (DIAGRAM 1 OF 6)
FROM FUSE 20 (DIAGRAM 1 OF 6) FUSE
FRONT FOG LIGHT RELAY
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH) (IF EQUIPPED)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW) (IF EQUIPPED)
FUSE
FUSE 14
FUSE 17
FUSE 18
FUSE 19
FUSE FUSE 1-5
GAUGE CONTROL MODULE (TACH)
GAUGE MULTI- CONTROL INFORMATION MODULE DISPLAY (SPEEDO) UNIT
GRN WIRE
HAZARD WARNING SWITCH
HORN RELAY
IGNITION COIL RELAY
LT BLU WIRE
LT GRN WIRE
MICU
PGM-FI SUB- RELAY
RED WIRE
STEREO AMPLIFIER (IF EQUIPPED)
TO ENGINE START/STOP SWITCH (DIAGRAM 6 OF 6)
TRUNK LIGHT
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WINDSHIELD WASHER MAIN RELAY
WINDSHIELD WIPER MOTOR RELAY
YEL WIRE
Go to component -> Power distribution circuit, except hybrid with keyless access (2 of 6) -> GRN WIRE
Wiring diagram grn (93 of 168)
1.8L
1.8L CVT
2.4L
BACKUP LIGHT SWITCH (M/T)
BLK/YEL WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER J/B 2
ECM/PCM
ELD
EPS CONTROL UNIT
EVAP CANISTER PURGE VALVE
FROM FUSE 2 (DIAGRAM 4 OF 6) FUSE 5
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 6 OF 6)
FUSE
FUSE 24
FUSE 3
FUSE 7
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
INHIBITOR RELAY UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
J/C
MAF EVAP SENSOR/ CANISTER IAT PURGE SENSOR VALVE
MAF SENSOR/ IAT SENSOR
MICU DIODE D
MOONROOF CONTROL UNIT/ MOTOR (IF EQUIPPED)
RED WIRE
REVERSE LOCKOUT SOLENOID
REVERSE RELAY CIRCUIT
SECONDARY
SENSOR 2
SHIFT LOCK SOLENOID
SRS UNIT
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STEERING ANGLE SENSOR
TO FUSE 29
TO FUSE 4 (DIAGRAM 5 OF 6)
TO FUSE 5 (DIAGRAM 4 OF 6)
TO UNDER- DASH FUSE/ RELAY BOX (DIAGRAM 3 OF 6)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid with keyless access (4 of 6) -> GRN WIRE
Wiring diagram grn (94 of 168)
1.8L
2.4L
2.4L 1.8L
AUDIO UNIT/ KEYLESS AUDIO-NAVIGATION ACCESS UNIT CONTROL UNIT
BLK WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
DASH)
ECM/PCM
FROM FUSE 19 (DIAGRAM 5 OF 6)
FROM FUSE 24 (DIAGRAM 4 OF 6) END OF DASH)
FROM FUSE 27 (DIAGRAM 1 OF 6)
FROM FUSE 5 (DIAGRAM 4 OF 6)
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 6 OF 6)
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
FRONT PASSENGER'S WEIGHT SENSOR UNIT
FUSE
FUSE 20
GRN WIRE
KEYLESS ACCESS CONTROL UNIT
MICU
PGM-FI MAIN RELAY 2
PPL
RIGHT END OF DASH)
SEDAN, COUPE
SRS UNIT
STEERING LOCK (2.4L)
TO FRONT ACCESSORY POWER SOCKET RELAY (DIAGRAM 5 OF 6)
UNDER- DASH FUSE/ RELAY BOX (UNDER LEFT END OF
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid with keyless access (5 of 6) -> GRN WIRE
Wiring diagram grn (95 of 168)
2.4L
ACC RELAY
BLK WIRE
BLU WIRE
ENGINE START/STOP SWITCH
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
GRN WIRE
GRY WIRE
IMMOBILIZER
KEYLESS ACCESS CONTROL UNIT
LF ANTENNA
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
STEERING LOCK (2.4L)
TO UNDER- DASH FUSE/ RELAY BOX (DIAGRAM 4 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
UNDER-DASH SUB-RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid with keyless access (6 of 6) -> GRN WIRE
Wiring diagram grn (96 of 168)
A/C COMPRESSOR CLUTCH RELAY
ALTERNATOR
BATTERY
BLK WIRE
BLOWER RADIATOR A/C MOTOR FAN RELAY CONDENSER RELAY FAN RELAY
BLU WIRE
D/L DR UNLOCK RELAY
DRIVER'S POWER SEAT ADJUSTMENT SWITCH (IF EQUIPPED)
ELD UNIT
EPS CONTROL UNIT
FUSE
FUSE 1 1
FUSE 1-6
FUSE 15
FUSE 16
FUSE 2-2 FUSE 2-1
FUSE 2-3
FUSE 2-4
FUSE 2-6
FUSE 25
FUSE 27 FUSE 41
FUSE FUSE
FUSE FUSE 1-3 1-4
FUSE FUSE FUSE
FUSE FUSE FUSE 2-8 2-10 2-11
FUSE FUSE FUSE FUSE
GRN WIRE
HEADLIGHT TAILLIGHT LOW BEAM RELAY RELAY
IGNITION COIL RELAY
MICU
MOONROOF/ SUNROOF CONTROL UNIT/MOTOR (IF EQUIPPED)
PGM-FI MAIN ETCS CONTROL RELAY 1 RELAY
PGM-FI SUB- RELAY
PNK WIRE
POWER WINDOW D/L UNLOCK TRUNK RELEASE RELAY RELAY ACTUATOR RELAY
POWER WINDOW MASTER SWITCH
PPL
REAR WINDOW DEFOGGER RELAY
RED WIRE
STARTER
TO FRONT ACCESSORY POWER SOCKET RELAY (DIAGRAM D/L LOCK 5 OF 5) RELAY
TO FUSE 14 (DIAGRAM 2 OF 5)
TO FUSE 28 (DIAGRAM 2 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 5)
UNDER- DASH FUSE/ RELAY BOX FUSE (UNDER LEFT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid without keyless access (1 of 5) -> GRN WIRE
Wiring diagram grn (97 of 168)
Go to component -> Rear camera circuit, except hybrid with multi-information display -> GRN WIRE
Wiring diagram grn (98 of 168)
Go to component -> Rear camera circuit, except hybrid without multi-information display -> GRN WIRE
Wiring diagram grn (99 of 168)
Go to component -> Rear camera circuit, hybrid with navigation -> GRN WIRE
Wiring diagram grn (100 of 168)
Go to component -> Rear camera circuit, hybrid without navigation -> GRN WIRE
