Trunk release circuit, hybrid for Honda Civic IX (2011-2015)
Trunk release circuit, hybrid
B-CAN
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
FUSE 41
FUSE 5
GAUGE CONTROL MODULE (TACH)
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 22
HOT IN ON OR START
INDICATOR
LT BLU WIRE
MAIN CIRCUIT
MICU
PNK WIRE
TAILGATE ACTUATOR RELAY
TRUNK IND
TRUNK LID LATCH SWITCH/TRUNK RELEASE ACTUATOR (MIDDLE OF TRUNK LID)
TRUNK LIGHT
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
