Transmission circuit, hybrid for Honda Civic IX (2011-2015)
Transmission circuit, hybrid (1 of 3)
A/T GEAR POSITION INDICATOR DRIVING CIRCUIT
APP SENSOR (CENTER OF DASH)
APP SENSOR A
APP SENSOR B
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE (ON TRANSMISSION LOWER VALVE BODY)
DIMMING CIRCUIT
F-CAN F-CAN F-CAN TRANSCEIVER
FAIL SAFE CIRCUIT
FORCED TURNING OFF CIRCUIT
FORCED TURNING ON CIRCUIT
FUEL PUMP
FUSE 11
FUSE 15
FUSE 23
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK PPL WIRE
PNK WIRE
PPL
PPL PNK PPL WIRE
RED WIRE
SHIFT INTERLOCK SYSTEM
STABILIZING CIRCUIT
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Transmission circuit, hybrid (2 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT INPUT SHAFT (DRIVE PULLEY) SPEED SENSOR (BOTTOM OF TRANSMISSION HOUSING)
CVT OUTPUT SHAFT (DRIVEN PULLEY) SPEED SENSOR (TOP OF TRANSMISSION HOUSING)
ENGINE CONTROLS SYSTEM
EVAP CANISTER PURGE VALVE (TOP REAR OF ENGINE)
FUSE
GAUGE CONTROL MODULE (SPEEDO)
GRN WIRE
GRY WIRE
HOT IN ON OR START
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) FUSE
INHIBITOR SOLENOID (ON TRANSMISSION LOWER VALVE BODY)
J/C
LT BLU WIRE
LT GRN WIRE
MAF SENSOR
MICU
ORG/ WIRE
PGM-FI MAIN RELAY 1
PNK PNK WIRE
PNK PPL WIRE
PNK WIRE
PPL
RED WIRE
TAN WIRE
VEHICLE SPEED SENSOR (IN TRANSMISSION)
WHT WIRE
YEL WIRE
Transmission circuit, hybrid (3 of 3)
ATF TEMPERATURE SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
CKP SENSOR (RIGHT REAR OF ENGINE)
CMP SENSOR (RIGHT REAR OF ENGINE)
CVT DRIVEN PULLEY PRESSURE SENSOR (ON TRANSMISSION HOUSING)
EGR VALVE/ EGR VALVE POSITION SENSOR
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK PNK PNK PNK PNK PNK WIRE
PNK PNK WIRE
PNK PPL WIRE
PNK WIRE
PPL
ROCKER ARM OIL CONTROL SOLENOID A
ROCKER ARM OIL CONTROL SOLENOID B
ROCKER ARM ROCKER OIL PRESSURE ARM OIL SENSOR A PRESSURE SENSOR B
TAN WIRE
WHT WIRE
YEL WIRE
