Premium radio circuit for Honda Civic IX (2011-2015)
Premium radio circuit (1 of 4)
AM/FM ANTENNA
AM/FM ANTENNA AMPLIFIER
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 29 BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LT BLU WIRE
MICU
NAVIGATION SYSTEM
ORG/ WIRE
PNK WIRE
PPL
RDS-TMC ANTENNA
RED WIRE
RIGHT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Premium radio circuit (2 of 4)
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
AUXILIARY JACK
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CHANNEL
GRN WIRE
GRY WIRE
INFO SWITCH
LT BLU WIRE
MENU SWITCH
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
STEREO AMPLIFIER
SWITCH
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Premium radio circuit (3 of 4)
Premium radio circuit (4 of 4)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SPEAKER
FRONT PASSENGER'S DOOR SPEAKER
FUSE 19
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR SPEAKER
LEFT TWEETER
LT GRN WIRE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
RIGHT REAR SPEAKER
RIGHT TWEETER
STEREO AMPLIFIER
SUBWOOFER
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
USB PORT A
USB PORT B
WHT WIRE
YEL WIRE
