Navigation circuit, except hybrid base for Honda Civic IX (2011-2015)

Navigation circuit, except hybrid base (1 of 4)

Civic Honda IX (2011-2015): Navigation circuit, except hybrid base (1 of 4)

Get access

AM/FM ANTENNA AM/FM ANTENNA AMPLIFIER AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 1 CENTER JUNCTION BOX 2 CENTER JUNCTION BOX 2 PPL COMPUTER DATA LINES SYSTEM FUSE 19 FUSE 29 BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC LT BLU WIRE LT GRN WIRE MICU NAVIGATION SYSTEM ORG/ WIRE PNK WIRE PPL RDS-TMC ANTENNA RED WIRE RIGHT END OF DASH) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-HOOD FUSE/RELAY WHT WIRE YEL WIRE

Navigation circuit, except hybrid base (2 of 4)

Civic Honda IX (2011-2015): Navigation circuit, except hybrid base (2 of 4)

Get access

18 19 PNK WIRE BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER WHT WIRE YEL WIRE

Navigation circuit, except hybrid base (3 of 4)

Civic Honda IX (2011-2015): Navigation circuit, except hybrid base (3 of 4)

Get access

18 19 PNK WIRE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE ORG/ WIRE PNK WIRE RED WIRE SIGNAL ANTENNA WHT WIRE XM ANTENNA XM RECEIVER (RIGHT SIDE OF TRUNK) YEL WIRE

Navigation circuit, except hybrid base (4 of 4)

Civic Honda IX (2011-2015): Navigation circuit, except hybrid base (4 of 4)

Get access

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH AUDIO UNIT/ AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CABLE REEL (ON STEERING COLUMN) CH- CH+ SWITCH SWITCH COMPUTER DATA LINES SYSTEM GPS ANTENNA GRN WIRE GRY WIRE INFO SWITCH MENU SWITCH NAVIGATION SYSTEM NCA WIRE PNK WIRE REARVIEW CAMERA RED WIRE SOURCE SWITCH USB PORT A USB PORT B VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE
