Hands free module circuit, hybrid for Honda Civic IX (2011-2015)

Hands free module circuit, hybrid (1 of 2)

Civic Honda IX (2011-2015): Hands free module circuit, hybrid (1 of 2)

Get access

18 19 PNK WIRE AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (TOP OF STEERING COLUMN) CENTER JUNCTION BOX 2 CHANNEL FUSE BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (RIGHT SIDE OF DASH) HFL- NAVIGATION VOICE CONTROL SWITCH HOT AT ALL TIMES INFO SWITCH MENU SWITCH NAVI BACK NAVI TALK ORG/ WIRE PNK WIRE PPL RED WIRE SOURCE SWITCH SWITCH UNDER-HOOD FUSE/RELAY VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Hands free module circuit, hybrid (2 of 2)

Civic Honda IX (2011-2015): Hands free module circuit, hybrid (2 of 2)

Get access

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 2 COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE ORG/ WIRE PNK 1 2 3 WIRE PNK 23 24 WIRE PNK PNK WIRE PNK WIRE REARVIEW CAMERA CIRCUIT RED WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) USB PORT B WHT WIRE YEL WIRE
