Hands free module circuit, except hybrid for Honda Civic IX (2011-2015)

Hands free module circuit, except hybrid (1 of 2)

Civic Honda IX (2011-2015): Hands free module circuit, except hybrid (1 of 2)

Get access

22 21 23 PNK WIRE 3 2 5 4 PNK WIRE AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL CABLE REEL (ON STEERING COLUMN) CENTER JUNCTION BOX 2 CHANNEL CHANNEL MENU SWITCH INFO SWITCH COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY WIRE HFL-NAVIGATION VOICE CONTROL SWITCH/ HFT-NAVIGATION VOICE CONTROL SWITCH HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT REAR OF ENGINE COMPT) HOT IN ON OR START LX EXCEPT LX MICROPHONE (IN ROOF CONSOLE) MICU NAVI NAVI TALK BACK ORG/ WIRE PNK WIRE PPL RED WIRE SOURCE SWITCH SWITCH UNDER-DASH FUSE/RELAY BOX VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Hands free module circuit, except hybrid (2 of 2)

Civic Honda IX (2011-2015): Hands free module circuit, except hybrid (2 of 2)

Get access

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CAMERA CIRCUIT COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE ORG/ WIRE PNK WIRE REARVIEW REARVIEW CAMERA CIRCUIT RED WIRE USB PORT A WHT WIRE YEL WIRE
