Entry light timer circuit, hybrid for Honda Civic IX (2011-2015)
Entry light timer circuit, hybrid
B-CANL B-CANH B CAN TRANSCEIVER
BLINKING CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
CEILING LIGHT
COMPUTER DATA LINES SYSTEM
COURTESY LAMPS CIRCUIT
DOOR ON
DOOR SWITCH (ON FRONT PASSENGER "B" PILLAR)
DRIVER'S DOOR SWITCH
FRONT PASSENGER'S
FUSE
FUSE 22 FUSE 23
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY LIGHT
IGNITION KEY SWITCH
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
MICU
OFF
PNK WIRE
REGULATOR
RIGHT REAR DOOR SWITCH
SECURITY IND
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
