Ground distribution circuit, except hybrid for Honda Civic IX (2011-2015)
Ground distribution circuit, except hybrid (1 of 5)
BATTERY
BATTERY SENSOR
BLK WIRE
BRN WIRE
CENTER J/B 1
CENTER JUNCTION BOX 1
CKP SENSOR
CMP SENSOR
CMP SENSOR B
DATA LINK CONNECTOR (DCL)
DATA LINK CONNECTOR (DLC)
EGR VALVE/ EGR VALVE POSITION SENSOR
ENGINE
EPS CONTROL UNIT
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION IGNITION COIL 3 COIL 1
IGNITION VTC OIL COIL 2 CONTROL SOLENOID VALVE
IMMOBILIZER KEYLESS CONTROL UNIT
KNOCK SENSOR SHIELD
KNOCK SENSOR SHIELD KNOCK SENSOR SHIELD
LG LG
ON BATTERY)
PCM
PG PG PG
RIGHT END OF DASH)
ROCKER ARM OIL CONTROL SOLENOID
ROCKER ARM OIL PRESSURE CMP SWITCH SENSOR A
ROCKER ARM OIL PRESSURE SWITCH
SECONDARY
SENSOR 2 SHIELD
STEERING GEAR BOX
TRANSMISSION HOUSING)
VSA MODULATOR CONTROL UNIT
YEL WIRE
Ground distribution circuit, except hybrid (2 of 5)
A/C CONDENSER FAN MOTOR
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH DIODE E
CABLE REEL
DATA LINK CONNECTOR (DLC)
ELD
FAN CONTROL RELAY
GAUGE GAUGE CONTROL CONTROL MODULE MODULE (TACH) (SPEEDO)
GRY WIRE
HFL-NAVIGATION VOICE CONTROL SWITCH/ HFT-NAVIGATION VOICE CONTROL SWITCH
IGNITION KEY SWITCH
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
M/T
MICU
POWER TRANSISTOR
RIGHT FOG LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
S GND
STEERING ANGLE SENSOR
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VSA OFF ECON SWITCH SWITCH
VSA OFF SWITCH
WINDOW WASHER MOTOR
WINDSHIELD WIPER INTERMITTENT RELAY
WINDSHIELD WIPER MOTOR
Ground distribution circuit, except hybrid (3 of 5)
BLK WIRE
BRN WIRE
COUPE
D/L LOCK RELAY
D/L OR UNLOCK RELAY
D/L UNLOCK RELAY
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
EX-L
EXCEPT EX-L
FRONT ACCESSORY POWER SOCKET RELAY
GAUGE CONTROL MODULE (TACH)
LEFT POWER MIRROR
MAIN RELAY
MULTI INFORMATION DISPLAY UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
TRUNK RELEASE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
WINDSHIELD WASHER
Ground distribution circuit, except hybrid (4 of 5)
BLK WIRE
COUPE
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FUEL TANK UNIT
HIGH MOUNT BRAKE LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR TURN LEFT SIGNAL BACKUP LIGHT LIGHT
LEFT TAILLIGHT/ BRAKE LIGHT
LICENSE PLATE LIGHT
REAR WINDOW DEFOGGER
RIGHT BACKUP LIGHT
RIGHT INNER TAILLIGHT
RIGHT REAR TRUNK LID TURN LATCH SWITCH/ SIGNAL TRUNK RELEASE ACTUATOR
RIGHT TAILLIGHT/ BRAKE LIGHT
SEDAN
SRS UNIT
TRUNK LID LATCH SWITCH/ TRUNK RELEASE LEFT ACTUATOR INNER TAILLIGHT
Ground distribution circuit, except hybrid (5 of 5)
4 DOOR, SECURITY
BLK WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT POSITION SENSOR
EX-L
EXCEPT EX-L
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S WEIGHT SENSOR UNIT
HVAC CONTROL CIRCUIT/ CLIMATE CONTROL UNIT
MICU
RIGHT END OF DASH)
S GND
SHIFT LEVER)
STEREO AMPLIFIER
W/ CLIMATE CONTROL W/O CLIMATE CONTROL
YEL WIRE
