Cruise control circuit, hybrid for Honda Civic IX (2011-2015)
Cruise control circuit, hybrid (1 of 2)
APP SENSOR A APP SENSOR (CENTER OF DASH)
APP SENSOR B
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT OUTPUT SHAFT (DRIVEN PULLEY) SPEED SENSOR (TOP OF TRANSMISSION HOUSING)
ETCS CONTROL RELAY
FUSE 2
GRN WIRE
GRY WIRE
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PGM-FI MAIN RELAY 1
PNK WIRE
PPL
RED WIRE
TAN WIRE
THROTTLE ACTUATOR THROTTLE BODY (LEFT REAR OF ENGINE)
THROTTLE OPEN SENSOR
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
WHT WIRE
YEL WIRE
Cruise control circuit, hybrid (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CANCEL SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL INDICATOR
CRUISE CONTROL/ SPEED LIMITER SWITCH
CRUISE MAIN INDICATOR
DIMMING CIRCUIT CIRCUIT
F-CAN H F-CAN L F-CAN TRANSCEIVER
FUSE
FUSE 11 ENGINE COMPT)
FUSE 15
FUSE 16
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR DRIVER CIRCUIT
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
MAIN SWITCH
MICU
RED WIRE
RES/+ SWITCH
SET SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF
WHT WIRE
YEL WIRE
