Honda Civic IX (2011-2015) windshield washer main relay Wiring diagrams
This page contains all the electrical diagrams for the component. windshield washer main relay, in which he is found in the car Honda Civic IX (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram windshield washer main relay (1 of 3)
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM ENGINE CONTROLS SYSTEM
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIODE
DOOR LOCKS, ANTI-THEFT SYSTEMS
DRIVER UNLOCK
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
EXTERIOR LIGHTS SYSTEM NAVIGATION, SOUND SYSTEMS
FUSE 21
FUSE 5
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HORNS SYSTEM
HOT IN ON
HOT IN ON OR
INSTRUMENT CLUSTER SYSTEM SHIFT INTERLOCK SYSTEM
LT BLU WIRE
LT GRN WIRE
MICU
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM INSTRUMENT CLUSTER SYSTEM
POWER WINDOW UNLOCK LOCK RELAY RELAY RELAY RELAY
PPL
REAR WINDOW WASHER MOTOR RELAY
RED WIRE
REVERSE RELAY
TAILGATE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
WARNING SYSTEMS
WHT WIRE
WINDSHIELD WASHER MAIN RELAY
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM HEADLIGHTS SYSTEM
YEL WIRE
Go to component -> Body control modules circuit, hybrid (1 of 2) -> WINDSHIELD WASHER MAIN RELAY
Wiring diagram windshield washer main relay (2 of 3)
7 6 W/ NAVIGATION W/O NAVIGATION
BATTERY
BATTERY SENSOR
BLK WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CKP SENSOR
CMP SENSOR
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER
DC/DC CONVERTER SHIELD
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
EGR VALVE/ EGR VALVE POSITION SENSOR
ENGINE
EPS CONTROL UNIT
EXHAUST SIDE IGNITION COIL 1
EXHAUST SIDE IGNITION COIL 2
EXHAUST SIDE IGNITION COIL 3
EXHAUST SIDE IGNITION COIL 4
GAUGE CONTROL MODULE (TACH)
GRN WIRE
IMMOBILIZER KEYLESS CONTROL UNIT
INTAKE SIDE IGNITION COIL 1
INTAKE SIDE IGNITION COIL 2
INTAKE SIDE IGNITION COIL 3
INTAKE SIDE IGNITION COIL 4
J/C
LEFT POWER MIRROR
LOCK RELAY TAILGATE ACTUATOR
MOTOR ROTOR POSITION SENSOR SHIELD
MULTI INFORMATION DISPLAY UNIT
OF DASH) FRONT ACCESSORY POWER SOCKET RELAY
PCM
POWER MIRROR SWITCH
POWER UNIT
POWER WINDOW MASTER SWITCH
RELAY
ROCKER ARM OIL CONTROL SOLENOID A
ROCKER ARM OIL CONTROL SOLENOID B
SERVO UNIT
TRANSMISSION HOUSING)
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END
UNLOCK RELAY
UNLOCK RELAY (DR)
VSA MODULATOR CONTROL UNIT
WINDSHIELD WASHER MAIN RELAY
Go to component -> Ground distribution circuit, hybrid (1 of 4) -> WINDSHIELD WASHER MAIN RELAY
Wiring diagram windshield washer main relay (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 28
FUSE 46 FUSE 5
GRN WIRE
HI LO
HOT IN ON OR START
LOW INT
MICU
MIST HIGH LOW OFF
MIST INTERMITTENT OFF INT DWELL TIME CONTROLLER WINDSHIELD WIPER SWITCH
OF DASH)
OFF WASH WASHER SWITCH
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PPL
RED WIRE
RELAY CONTROL MODULE (IN UNDER-HOOD FUSE/RELAY BOX)
TAN WIRE
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END
WHT WIRE
WINDSHIELD WASHER MAIN RELAY
WINDSHIELD WASHER MOTOR (IN WASHER FLUID RESERVOIR)
WINDSHIELD WIPER HIGH/LOW RELAY
WINDSHIELD WIPER INTERMITTENT RELAY
WINDSHIELD WIPER MOTOR (UNDER RIGHT SIDE OF COWL COVER)
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit, hybrid -> WINDSHIELD WASHER MAIN RELAY
