Honda Civic IX (2011-2015) volume down switch volume up switch Wiring diagram
This page shows the only wiring diagram for the component.volume down switch volume up switch, which is found in the car Honda Civic IX (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram volume down switch volume up switch (1 of 1)
18 19 PNK WIRE
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CENTER JUNCTION BOX 2
CHANNEL
FUSE BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (RIGHT SIDE OF DASH)
HFL- NAVIGATION VOICE CONTROL SWITCH
HOT AT ALL TIMES
INFO SWITCH
MENU SWITCH
NAVI BACK
NAVI TALK
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
SOURCE SWITCH
SWITCH
UNDER-HOOD FUSE/RELAY
VOLUME DOWN SWITCH VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Hands free module circuit, hybrid (1 of 2) -> VOLUME DOWN SWITCH VOLUME UP SWITCH
