Honda Civic IX (2011-2015) sub amplifier Wiring diagram
This page shows the only wiring diagram for the component.sub amplifier, which is found in the car Honda Civic IX (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sub amplifier (1 of 1)
AM/FM, XM ANTENNA
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
COMPUTER DATA PNK LINES SYSTEM WIRE
FUSE 19
FUSE 23 BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LT BLU WIRE
LT GRN WIRE
MCM
MICU
ORG/ WIRE
PCM
PNK WIRE
PPL
RED WIRE
SUB AMPLIFIER
TAN WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Go to component -> Base radio circuit, hybrid without navigation (1 of 4) -> SUB AMPLIFIER
