Honda Civic IX (2011-2015) security indicator led Wiring diagrams
This page contains all the electrical diagrams for the component. security indicator led, in which he is found in the car Honda Civic IX (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram security indicator led (1 of 2)
"B" PILLAR)
"C" PILLAR)
4 5 6 PNK WIRE
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLINKING
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
DOOR INDICATOR (LED)
DOOR LOCK
DOOR LOCK KNOB
DOOR LOCK KNOB KEY
DRIVE CIRCUIT
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
FRONT PASSENGER'S
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (IN RIGHT
FUSE
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN)
INDICATOR
KNOB SWITCH
LEFT REAR
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (SEDAN)
LEFT REAR DOOR SWITCH (SEDAN) (IN LEFT
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
PNK WIRE
REGULATOR
RIGHT END OF DASH)
RIGHT REAR
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (SEDAN)
RIGHT REAR DOOR SWITCH (SEDAN) (IN RIGHT "C" PILLAR)
SECURITY INDICATOR LED
TRUNK LATCH SWITCH
TRUNK LID LATCH SWITCH/TRUNK RELEASE ACTUATOR (MIDDLE OF TRUNK LID)
TRUNK RELEASE ACTUATOR
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, except hybrid (2 of 2) -> SECURITY INDICATOR LED
