Honda Civic IX (2011-2015) pnk shift interlock system Wiring diagrams
This page contains all the electrical diagrams for the component. pnk shift interlock system, in which he is found in the car Honda Civic IX (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk shift interlock system (1 of 2)
8 6 5 11 10 9 12 7 PPL PPL PPL
A/T GEAR POSITION
AIR CONDITIONING SYSTEM
APP SENSOR (CENTER OF DASH)
APP SENSOR A
APP SENSOR B
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
DIMMING CIRCUIT
DRIVING
EPS CONTROL UNIT (RIGHT KICK PANEL)
F-CAN
F-CAN H
F-CAN L
FTP SENSOR (FRONT OF FUEL TANK, ON FUEL LINE)
FUSE 9
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR
INDICATOR DRIVING CIRCUIT
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
MIL IND
NAVIGATION, SOUND SYSTEMS
ORG/ WIRE
PCM (POWERTRAIN CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT)
PGM-FI SUB- RELAY
PNK SHIFT INTERLOCK SYSTEM WIRE
PNK WIRE
PPL
PPL PPL
RED WIRE
STARTING/ CHARGING SYSTEM
TRANSCEIVER/
UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l hybrid, engine controls circuit (1 of 5) -> PNK SHIFT INTERLOCK SYSTEM WIRE
Wiring diagram pnk shift interlock system (2 of 2)
A/C CONDENSER FAN RELAY
A/T
A/T GEAR POSITION INDICATOR DRIVING CIRCUIT
AIR CONDITIONING SYSTEM
APP SENSOR (LEFT REAR OF ENGINE COMPT)
APP SENSOR A
APP SENSOR B
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM COOLING FANS SYSTEM COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM NAVIGATION SYSTEM
DIMMING CIRCUIT
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
EPS CONTROL UNIT (BEHIND RIGHT KICK PANEL)
F-CAN
F-CAN H
F-CAN L
FTP SENSOR (UNDER REAR SEATS)
FUSE
FUSE DIODE
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE
HOT IN ON OR START UNDER- DASH FUSE/ RELAY BOX (UNDER LEFT END OF DASH) FUSE
INDICATOR DRIVE CIRCUIT
LT BLU WIRE
LT GRN WIRE
M/T
MAIN CIRCUIT
MIL IND
ORG/ WIRE
PGM-FI SUB- RELAY
PNK SHIFT INTERLOCK SYSTEM WIRE
PPL
RED WIRE
TRANSCEIVER/
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.8l (1 of 5) -> PNK SHIFT INTERLOCK SYSTEM WIRE
