Honda Civic IX (2011-2015) map lt sw Wiring diagram
This page shows the only wiring diagram for the component.map lt sw, which is found in the car Honda Civic IX (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram map lt sw (1 of 1)
A/T
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTO AUTO CLOSE OPEN
AUTO AUTO OPEN CLOSE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 2
CLOSE
COMPUTER DATA LINES SYSTEM
DOOR SWITCH (IN RIGHT "B" PILLAR)
DRIVER'S DOOR
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYCLINDER
DRIVER'S DOOR SWITCH (IN RIGHT "B" PILLAR)
FRONT PASSENGER'S
FUSE 11
GRN WIRE
HALL SENSOR
HOT AT ALL TIMES
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (UNDER LEFT FUSE 6 END OF DASH)
J/C
KEY CYLINDER SWITCH
KEY/DOOR LOCK KNOB
LOCK
LT BLU WIRE
LT GRN WIRE
M/T
MAP LT SW
MICU
MOONROOF/SUNROOF CONTROL UNIT/MOTOR (CENTER REAR OF MOON ROOF)
MOONROOF/SUNROOF SWITCH/INTERIOR LIGHT SWITCH
MOTOR
OFF OPEN CLOSE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PPL
RED WIRE
SWITCH
TILT SW (LEFT END OF DASH)
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> MAP LT SW
