Honda Civic IX (2011-2015) left rear speaker Wiring diagrams

This page contains all the electrical diagrams for the component. left rear speaker, in which he is found in the car Honda Civic IX (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

left rear speaker wiring diagram (1 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (1 of 7)

18 19 PNK WIRE BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER WHT WIRE YEL WIRE

Go to component -> Base radio circuit, except hybrid with navigation (2 of 4) -> LEFT REAR SPEAKER

left rear speaker wiring diagram (2 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (2 of 7)

AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER WHT WIRE YEL WIRE

Go to component -> Base radio circuit, hybrid with navigation (2 of 4) -> LEFT REAR SPEAKER

left rear speaker wiring diagram (3 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (3 of 7)

BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 2 DIODE D DRIVER'S DOOR SPEAKER END OF DASH) FRONT PASSENGER'S DOOR SPEAKER FUSE 5 GRN WIRE GRY WIRE HOT IN ON OR START LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE MICU ORG/ WIRE PNK WIRE PPL RED WIRE REVERSE RELAY RIGHT REAR SPEAKER RIGHT TWEETER TAN WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT WHT WIRE YEL WIRE

Go to component -> Base radio circuit, hybrid without navigation (2 of 4) -> LEFT REAR SPEAKER

left rear speaker wiring diagram (4 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (4 of 7)

18 19 PNK WIRE BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER WHT WIRE YEL WIRE

Go to component -> Navigation circuit, except hybrid base (2 of 4) -> LEFT REAR SPEAKER

left rear speaker wiring diagram (5 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (5 of 7)

AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid base (2 of 4) -> LEFT REAR SPEAKER

left rear speaker wiring diagram (6 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (6 of 7)

AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER FUSE 19 GPS ANTENNA GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER STEREO AMPLIFIER SUBWOOFER UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) USB PORT A USB PORT B WHT WIRE YEL WIRE

Go to component -> Navigation circuit, premium (4 of 4) -> LEFT REAR SPEAKER

left rear speaker wiring diagram (7 of 7)

Honda Civic IX (2011-2015) left rear speaker wiring diagram (7 of 7)

AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER FUSE 19 GPS ANTENNA GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER STEREO AMPLIFIER SUBWOOFER UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) USB PORT A USB PORT B WHT WIRE YEL WIRE

Go to component -> Premium radio circuit (4 of 4) -> LEFT REAR SPEAKER
