Honda Civic IX (2011-2015) left rear Wiring diagrams
This page contains all the electrical diagrams for the component. left rear, in which he is found in the car Honda Civic IX (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear (1 of 5)
BLK WIRE
BRN WIRE
FUSE 14
FUSE 27
FUSE 29 FUSE 17
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HIGH MOUNT BRAKE LIGHT (EXCEPT HIGH MOUNT BRAKE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
LEFT INNER TAILLIGHT (SEDAN)
LEFT LICENSE PLATE LIGHT (SEDAN)
LEFT REAR
LEFT TAILLIGHT/ BRAKE LIGHT
LICENSE RIGHT PLATE LICENSE LIGHT PLATE (COUPE) LIGHT (SEDAN)
LIGHT (SI) SI)
LT GRN WIRE
ORG/ WIRE
RED WIRE
RIGHT INNER TAILLIGHT (SEDAN)
RIGHT REAR SIDE MARKER LIGHT (SEDAN)
RIGHT TAILLIGHT/ BRAKE LIGHT
SEDAN, COUPE
SIDE MARKER LIGHT (SEDAN)
TAILLIGHT RELAY
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, except hybrid (2 of 2) -> LEFT REAR
Wiring diagram left rear (2 of 5)
"B" PILLAR)
"C" PILLAR)
4 5 6 PNK WIRE
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLINKING
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
DOOR INDICATOR (LED)
DOOR LOCK
DOOR LOCK KNOB
DOOR LOCK KNOB KEY
DRIVE CIRCUIT
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
FRONT PASSENGER'S
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (IN RIGHT
FUSE
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN)
INDICATOR
KNOB SWITCH
LEFT REAR
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (SEDAN)
LEFT REAR DOOR SWITCH (SEDAN) (IN LEFT
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
PNK WIRE
REGULATOR
RIGHT END OF DASH)
RIGHT REAR
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (SEDAN)
RIGHT REAR DOOR SWITCH (SEDAN) (IN RIGHT "C" PILLAR)
SECURITY INDICATOR LED
TRUNK LATCH SWITCH
TRUNK LID LATCH SWITCH/TRUNK RELEASE ACTUATOR (MIDDLE OF TRUNK LID)
TRUNK RELEASE ACTUATOR
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, except hybrid (2 of 2) -> LEFT REAR
Wiring diagram left rear (3 of 5)
"B" PILLAR)
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLINKING CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR INDICATOR (LED)
DOOR LOCK
DOOR LOCK KNOB
DRIVE CIRCUIT
DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR)
FRONT PASSENGER'S
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (ON RIGHT
FUSE
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR
KEYLESS ACCESS SYSTEM INDICATOR (LED)
KNOB SWITCH
LEFT REAR
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
LEFT REAR DOOR SWITCH (ON LEFT "C" PILLAR)
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
PNK WIRE
RIGHT END OF DASH)
RIGHT REAR
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
RIGHT REAR DOOR SWITCH (ON RIGHT "C" PILLAR)
SECURITY IND
TRUNK LATCH SWITCH
TRUNK RELEASE ACTUATOR
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, hybrid (2 of 2) -> LEFT REAR
Wiring diagram left rear (4 of 5)
"B" PILLAR)
"C" PILLAR)
4 5 6 PNK WIRE
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLINKING
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
DOOR INDICATOR (LED)
DOOR LOCK
DOOR LOCK KNOB
DOOR LOCK KNOB KEY
DRIVE CIRCUIT
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
FRONT PASSENGER'S
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (IN RIGHT
FUSE
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN)
INDICATOR
KNOB SWITCH
LEFT REAR
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (SEDAN)
LEFT REAR DOOR SWITCH (SEDAN) (IN LEFT
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
PNK WIRE
REGULATOR
RIGHT END OF DASH)
RIGHT REAR
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH (SEDAN)
RIGHT REAR DOOR SWITCH (SEDAN) (IN RIGHT "C" PILLAR)
SECURITY INDICATOR LED
TRUNK LATCH SWITCH
TRUNK LID LATCH SWITCH/TRUNK RELEASE ACTUATOR (MIDDLE OF TRUNK LID)
TRUNK RELEASE ACTUATOR
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, except hybrid (2 of 2) -> LEFT REAR
Wiring diagram left rear (5 of 5)
"B" PILLAR)
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLINKING CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR INDICATOR (LED)
DOOR LOCK
DOOR LOCK KNOB
DRIVE CIRCUIT
DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR)
FRONT PASSENGER'S
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (ON RIGHT
FUSE
GAUGE CONTROL MODULE (SPEEDO)
GAUGE CONTROL MODULE (TACH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR
KEYLESS ACCESS SYSTEM INDICATOR (LED)
KNOB SWITCH
LEFT REAR
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
LEFT REAR DOOR SWITCH (ON LEFT "C" PILLAR)
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
PNK WIRE
RIGHT END OF DASH)
RIGHT REAR
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
RIGHT REAR DOOR SWITCH (ON RIGHT "C" PILLAR)
SECURITY IND
TRUNK LATCH SWITCH
TRUNK RELEASE ACTUATOR
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, hybrid (2 of 2) -> LEFT REAR
