Honda Civic IX (2011-2015) clutch interlock switch (under left Wiring diagram
This page shows the only wiring diagram for the component.clutch interlock switch (under left, which is found in the car Honda Civic IX (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clutch interlock switch (under left (1 of 1)
A/T
BATTERY
BATTERY SENSOR
BLK WIRE
BLU WIRE
CLUTCH INTERLOCK SWITCH (UNDER LEFT
DIODE E (IN UNDERHOOD FUSE/RELAY BOX)
FUSE 1-6
FUSE 2-1
FUSE 5
IGNITION SWITCH
LOCK
M/T
ORG/ WIRE
RED WIRE
SIDE OF DASH)
STARTER CUT RELAY
STARTER MAGNETIC SWITCH
STARTER MOTOR
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Starting circuit, except hybrid -> CLUTCH INTERLOCK SWITCH (UNDER LEFT
