Honda Civic IX (2011-2015) audio unit/ audio navigation unit Wiring diagrams
This page contains all the electrical diagrams for the component. audio unit/ audio navigation unit, in which he is found in the car Honda Civic IX (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram audio unit/ audio navigation unit (1 of 22)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTOMATIC LIGHTING CONTROL UNIT (IF EQUIPPED) (TOP CENTER OF DASH)
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
FUSE 29
GAUGE CONTROL MODULE (TACH)
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
HVAC CONTROL UNIT/CLIMATE CONTROL UNIT (IF EQUIPPED)
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN)
LT GRN WIRE
MICU
MULTI INFORMATION DISPLAY UNIT
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> B-can circuit & s-net circuit, except hybrid -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (2 of 22)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTOMATIC LIGHTING/ SUNLIGHT SENSOR (TOP CENTER OF DASH)
BLK WIRE
BLU PNK WIRE
BLU WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
FUSE 23
GAUGE CONTROL MODULE (TACH)
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
IMMOBILIZER KEYLESS CLIMATE CONTROL UNIT CONTROL UNIT (IN STEERING COLUMN)
LT GRN WIRE
MICU
MULTI INFORMATION DISPLAY UNIT
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
WHT WIRE
Go to component -> B-can circuit & s-net circuit, hybrid -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (3 of 22)
A/T
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BRN WIRE
BRN/YEL WIRE
CENTER JUNCTION BOX 1
DLC (UNDER LEFT SIDE OF DASH)
FRONT PASSENGER'S WEIGHT SENSOR UNIT
FUSE 29
GAUGE CONTROL MODULE (TACH)
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN)
LT BLU WIRE
LX, EX-2 SI
M/T
MICU
RED WIRE
SEDAN, COUPE
SRS UNIT (UNDER MIDDLE OF DASH)
STEERING ANGLE SENSOR (IN STEERING COLUMN COVER)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
WHT WIRE
Go to component -> Data link connector circuit, except hybrid (1 of 2) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (4 of 22)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BRN WIRE
CENTER JUNCTION BOX 1
DLC (UNDER LEFT SIDE OF DASH)
FCW/LDW CAMERA UNIT (TOP CENTER OF WINDSHIELD)
FRONT PASSENGER'S WEIGHT SENSOR UNIT
FUSE
GAUGE CONTROL MODULE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN)
J/C
LT BLU WIRE
MICU
RED WIRE
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
STEERING ANGLE SENSOR (TOP OF STEERING COLUMN)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> Data link connector circuit, hybrid (1 of 2) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (5 of 22)
3 6 W/ NAVIGATION W/O NAVIGATION
A/C COMPRESSOR DRIVER
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK-PIN SWITCH
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTOMATIC LIGHTING/SUNLIGHT SENSOR
BATTERY MODULE
BLK WIRE
CLIMATE CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT POSITION SENSOR
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S WEIGHT SENSOR UNIT
IPU FAN MODULE
IPU MODULE COMPT)
J/C
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
MCM
MICU
MOTOR ROTOR POSITION SENSOR SHIELD
MPI MODULE
RIGHT END OF DASH)
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
Go to component -> Ground distribution circuit, hybrid (4 of 4) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (6 of 22)
AM/FM ANTENNA
AM/FM ANTENNA AMPLIFIER
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CENTER JUNCTION BOX 2 PPL
COMPUTER DATA LINES SYSTEM
FUSE 19
FUSE 29 BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LT BLU WIRE
LT GRN WIRE
MICU
NAVIGATION SYSTEM
ORG/ WIRE
PNK WIRE
PPL
RDS-TMC ANTENNA
RED WIRE
RIGHT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, except hybrid base (1 of 4) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (7 of 22)
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUXILIARY JACK ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (ON STEERING COLUMN)
CH- CH+ SWITCH SWITCH
COMPUTER DATA LINES SYSTEM
GPS ANTENNA
GRN WIRE
GRY WIRE
INFO SWITCH
MENU SWITCH
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
REARVIEW CAMERA
RED WIRE
SOURCE SWITCH
USB PORT A
USB PORT B
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, except hybrid base (4 of 4) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (8 of 22)
AM/FM, XM ANTENNA
AMPLIFIER AMP
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
COMPUTER DATA PNK LINES SYSTEM WIRE
FUSE 19
FUSE 23 BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT "C" PILLAR)
LNA
LT BLU WIRE
LT GRN WIRE
MCM
MICU
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PCM
PNK WIRE
PPL
RDS-TMC ANTENNA
RED WIRE
RIGHT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, hybrid base (1 of 4) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (9 of 22)
AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CHANNEL
COMPUTER DATA LINES SYSTEM
GPS ANTENNA
GRN WIRE
GRY WIRE
INFO SWITCH
MENU SWITCH
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
RED WIRE
SOURCE SWITCH
SWITCH
USB PORT A
USB PORT B
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, hybrid base (4 of 4) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
Wiring diagram audio unit/ audio navigation unit (10 of 22)
AM/FM ANTENNA
AM/FM ANTENNA AMPLIFIER
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 29 BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LT BLU WIRE
MICU
NAVIGATION SYSTEM
ORG/ WIRE
PNK WIRE
PPL
RDS-TMC ANTENNA
RED WIRE
RIGHT END OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, premium (1 of 4) -> AUDIO UNIT/ AUDIO NAVIGATION UNIT
