Car Wiring Diagrams for Shift interlock circuit for Honda Civic IV (1987-1996)

A/T GEAR POSITION SWITCH BLK WIRE BRAKE SWITCH (LEFT I/P) ENGINE CONTROL MODULE (RIGHT KICK PANEL) FUSE 42 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (LEFT SIDE OF I/P) FUSE 15 INSTRUMENT CLLUSTER SYSTEM INTERLOCK CONTROL UNIT (RIGHT SIDE OF I/P) KEY INTERLOCK SOLENOID KEY INTERLOCK SWITCH PNK/BLK WIRE RED WIRE RED/BLU WIRE SHIFT LOCK SOLENOID (BELOW CENTER CONSOLE) THROTTLE POSITION SENSOR CENTER REAR OF ENGINE) UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT) WHT GRN/ WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
