Moonroof circuit, sedan for Honda Civic IV (1987-1996)
Moonroof circuit, sedan
BLK WIRE
BLU WIRE
CLOSE
FUSE 1
FUSE 14
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
MOONROOF CLOSE RELAY (BEHIND LEFT END OF I/P)
MOONROOF MOTOR (CENTER REAR OF ROOF)
MOONROOF OPEN RELAY (BEHIND LEFT END OF I/P)
MOONROOF SWITCH
OPEN TILT
OPEN/CLOSE SWITCH (CENTER REAR OF ROOF)
RED WIRE
TILT
TILT/CLOSE SWITCH (CENTER REAR OF ROOF)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF I/P)
WHT WIRE
YEL WIRE
YEL/RED WIRE
