Exterior light circuit, hatchback for Honda Civic IV (1987-1996)
Exterior light circuit, hatchback
BLK WIRE
BRAKE LIGHT SWITCH (LEFT SIDE OF I/P)
FROM HAZARD WARNING SWITCH
FROM TURN SIGNAL SWITCH
FUSE 40 LIGHT
FUSE 42 STOP, HORN
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD OFF PARK
HEADLIGHT SWITCH COMBINATION LIGHT SWITCH
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
LEFT FRONT FENDER)
LEFT FRONT PARKING/TURN SIGNAL LIGHT
LEFT INNER TAILLIGHT LEFT OUTER BRAKE/TAIL- LIGHT
LEFT LICENSE LIGHT
LEFT OUTER TAILLIGHT
LEFT TURN SIGNAL LIGHT
NCA WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT PARKING/TURN SIGNAL LIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE LIGHT
RIGHT OUTER BRAKE/TAIL- LIGHT
RIGHT OUTER TAILLIGHT
RIGHT TURN SIGNAL LIGHT
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF I/P) FUSE 19
UNDER-HOOD FUSE/RELAY BOX
W/ CRUISE CONTROL
W/O CRUISE CONTROL
WHT WIRE
WHT/GRN WIRE
