Honda Civic IV (1987-1996) left horn switch Wiring diagrams
This page contains all the electrical diagrams for the component. left horn switch, in which he is found in the car Honda Civic IV (1987-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left horn switch (1 of 2)
BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
CABLE REEL
CRUISE CONTROL JUMPER
CRUISE SET/ RESUME SWITCH
FUSE 42
GRN/ WHT WIRE
GRY WIRE
HIGH HORN (BEHIND FRONT BUMPER, LEFT SIDE)
HORN RELAY (UNDER-DASH FUSE/RELAY BOX)
HOT AT ALL TIMES
LEFT HORN SWITCH
LOW HORN (BEHIND FRONT BUMPER, RIGHT SIDE)
NCA WIRE
RIGHT HORN SWITCH
SECURITY SYSTEM CONNECTOR (OPTION)
STEERING WHEEL)
UNDER-HOOD FUSE/RELAY BOX
W/ CRUISE
W/ DUAL HORN
W/O CRUISE
WHT GRN/ WIRE
WHT/GRN WIRE
Go to component -> Horn circuit -> LEFT HORN SWITCH
Wiring diagram left horn switch (2 of 2)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
CABLE REEL
CRUISE SET/ RESUME SWITCH
FUSE 42 STOP,HORN
GRN WIRE
GRN/ BLU WIRE
GRY WIRE
HORN (BEHIND RIGHT FRONT BUMPER)
HORN RELAY (UNDER-DASH FUSE/RELAY BOX)
HOT AT ALL TIMES
LEFT HORN SWITCH
NCA WIRE
RIGHT HORN SWITCH
SECURITY SYSTEM CONNECTOR
STEERING WHEEL)
UNDER- HOOD FUSE/ RELAY BOX
W/ CRUISE
W/O CRUISE
WHT/GRN WIRE
Go to component -> Horn circuit, with air bag -> LEFT HORN SWITCH
