Honda Civic IV (1987-1996) bulb check unit Wiring diagrams
This page contains all the electrical diagrams for the component. bulb check unit, in which he is found in the car Honda Civic IV (1987-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bulb check unit (1 of 2)
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BULB CHECK UNIT
DRIVER'S DOOR SWITCH
FUSE 15
FUSE 18
FUSE 3
GRN/BLU WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN START
IGNITION KEY SWITCH
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT CLUSTERS SYSTEM
INTEGRATED CONTROL UNIT
PASS- ENGER'S DOOR SWITCH
RED WIRE
RED/BLU WIRE
SEAT BELT REMINDER/ KEY-IN BEEPER CIRCUIT
SEAT BELT SWITCH
UNDER-DASH FUSE/RELAY BOX (LEFT SIDE OF I/P)
WIPER/WASHER SYSTEM
Go to component -> Seat belt/key-in warning circuit -> BULB CHECK UNIT
Wiring diagram bulb check unit (2 of 2)
ANTI-THEFT SYSTEM
BLK WIRE
BLU/WHT WIRE
BULB CHECK UNIT
DRIVER'S DOOR SWITCH
DRIVER'S SEAT BELT SWITCH
FRONT PASSENGER'S DOOR SWITCH
FUSE 15
FUSE 18
FUSE 3
GRN/BLU WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN START
IGNITION KEY SWITCH
INSTRUMENT CLUSTER SYSTEM
INTEGRATED CONTROL UNIT
LT GRN RED/ WIRE
LT GRN/RED WIRE
RED/BLU WIRE
SEAT BELT REMINDER/ KEY-IN BEEPER CIRCUIT
UNDER-DASH FUSE/RELAY BOX (LEFT SIDE OF I/P)
WIPER/WASHER SYSTEM
Go to component -> Warning system circuits -> BULB CHECK UNIT
