Power antenna circuit for Honda Civic II (1979-1997)
Power antenna circuit
BLK WIRE
FUSE 23
HOT AT ALL TIMES
HOT IN ACC OR RUN
IN-LINE FUSE HOLDER A (BEHIND LOWER LEFT OF DASH)
LIMIT SWITCHES
OFF ON
OPTION FUSE 36
POWER ANTENNA MOTOR (BEHIND RIGHT SIDE LOWER TRIM PANEL)
POWER ANTENNA RELAY
STEREO RADIO/ CASSETTE PLAYER
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPARTMENT)
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
YEL/WHT WIRE
