Exterior light circuit, hatchback for Honda Civic II (1979-1997)

Exterior light circuit, hatchback (1 of 2)

Civic Honda II (1979-1997): Exterior light circuit, hatchback (1 of 2)

Get access

BLK WIRE BRAKE LIGHT SWITCH (LEFT SIDE OF I/P) COMBINATION LIGHT SWITCH GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHT SWITCH HEAD OFF PARK HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES J/C LEFT FRONT FENDER) LEFT FRONT PARKING/TURN SIGNAL LIGHT LEFT INNER TAILLIGHT LEFT LICENSE LIGHT LEFT OUTER BRAKE/TAIL- LIGHT LEFT OUTER TAILLIGHT LEFT TURN SIGNAL LIGHT LIGHT FUSE 40 RED/BLK WIRE RED/GRN WIRE RIGHT FRONT PARKING/TURN SIGNAL LIGHT RIGHT INNER TAILLIGHT RIGHT LICENSE LIGHT RIGHT OUTER BRAKE/TAIL- LIGHT RIGHT OUTER TAILLIGHT RIGHT TURN SIGNAL LIGHT STOP, HORN FUSE 42 TO HAZARD WARNING SWITCH (DIAGRAM 2 OF 2) TO TURN SIGNAL SWITCH (DIAGRAM 2 OF 2) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF I/P) FUSE 19 UNDER-HOOD FUSE/RELAY BOX W/ CRUISE CONTROL W/O CRUISE CONTROL WHT WIRE WHT/GRN WIRE

Exterior light circuit, hatchback (2 of 2)

Civic Honda II (1979-1997): Exterior light circuit, hatchback (2 of 2)

Get access

BLK WIRE COMBINATION LIGHT SWITCH FROM LEFT FRONT PARKING/TURN SIGNAL LIGHT (DIAGRAM 1 OF 2) FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 2) GAUGE ASSEMBLY GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND HAZARD FUSE 43 HAZARD WARNING SWITCH HOT AT ALL TIMES HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX FUSE 15 (BEHIND LEFT SIDE OF I/P) IGNITION ILLUMINATION J/C LEFT LEFT TURN INDIC OFF ON (NOT USED) RED WIRE RED/BLK WIRE RELAY OUT RIGHT RIGHT TURN INDIC TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD RELAY UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF I/P) UNDER-HOOD FUSE/RELAY BOX WHT/GRN WIRE YEL WIRE
