Exterior lamps circuit for Honda Civic II (1979-1997)
Exterior lamps circuit (1 of 2)
BLK WIRE
BRAKE LIGHT SWITCH (LEFT SIDE OF I/P)
COMBINATION LIGHT SWITCH
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHT SWITCH HEAD OFF PARK
HIGH MOUNT BRAKE LIGHT (LED)
HOT AT ALL TIMES
LEFT BRAKE/ TAILLIGHT
LEFT FRONT FENDER)
LEFT FRONT PARKING/TURN SIGNAL LIGHT
LEFT LICENSE LIGHT
LEFT REAR PARKING LIGHT
LEFT TURN SIGNAL LIGHT
LIGHT FUSE 40
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT BRAKE/ TAILLIGHT
RIGHT FRONT PARKING/TURN SIGNAL LIGHT
RIGHT LICENSE LIGHT
RIGHT REAR PARKING LIGHT
RIGHT TURN SIGNAL LIGHT
STOP, HORN FUSE 42
TO GAUGE ASSEMBLY (DIAGRAM 2 OF 2)
TO TURN SIGNAL/HAZARD RELAY (DIAGRAM 2 OF 2)
UNDER-HOOD FUSE/RELAY BOX
W/ CRUISE CONTROL
W/O CRUISE CONTROL
WHT WIRE
WHT/GRN WIRE
Exterior lamps circuit (2 of 2)
BLK WIRE
COMBINATION LIGHT SWITCH
FROM FRONT PARKING/ TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FUSE 15 BACK-UP LIGHT
GAUGE ASSEMBLY
GRN/BLU WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HOT IN ON OR START
ILLUMINATION
LEFT
LEFT TURN IND
OFF
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT
RIGHT TURN IND
TURN SIGNAL DIODE (ABOVE UNDER-DASH FUSE/RELAY BOX)
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY (BEHIND LEFT SIDE OF I/P)
UNDER-DASH FUSE/RELAY BOX
WHT/GRN WIRE
YEL WIRE
YEL/WHT WIRE
