Honda Civic GA (1998-2002) steering pump bracket Wiring diagram
This page shows the only wiring diagram for the component.steering pump bracket, which is found in the car Honda Civic GA (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering pump bracket (1 of 1)
1.6L DOHC VTEC 1.6L SOHC VTEC-E 1.6L SOHC 1.6L SOHC VTEC
A/T
A/T CVT
A/T GEAR POSITION SWITCH
A/T: CVT MODEL
ABS CONTROL UNIT
BATTERY
BLK WIRE
BLOWER MOTOR HIGH RELAY ABS PUMP MOTOR
BLOWER MOTOR RELAY
BRN WIRE
BRN/BLK WIRE
CANADA
CKF SENSOR SHIELD
CRANKSHAFT SPEED FLUCTUATION (CKF) SENSOR
CRUISE CONTROL ACTUATOR WINDSHIELD WASHER MOTOR
CVT
CVT SHIELD
DRIVE PULLEY SPEED SENSOR SHIELD
DRIVER PULLEY SPEED SENSOR SHIELD (2) OR COUNTERSHAFT SPEED SENSOR SHIELD (3, 4)
ELECTRICAL LOAD DETECTOR (ELD) UNIT
EXHAUST GAS RECIRCULATION (EGR) CONTROL SOLENOID VALVE
EXHAUST GAS RECIRCULATION (EGR) VALVE, LIFT SENSOR
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR (PRIMARY
HEATED OXYGEN SENSOR (SECONDARY
HEATER CONTROL PANEL
KNOCK SENSOR (KS) SHIELD
LEFT FRONT PARKING/ TURN SIGNAL LIGHT
LEFT HEADLIGHT
PGM-FI MAIN RELAY VTEC PRESSURE SWITCH
POWER STEERING PRESSURE (PSP) SWITCH ENGINE COOLANT TEMPERATURE (ECT) SWITCH
POWER TRANSISTOR
POWERTRAIN CONTROL MODULE (PCM) OR ENGINE CONTROL MODULE (ECM)
RADIATOR FAN MOTOR
REAR WINDOW WASHER MOTOR
RIGHT FRONT PARKING/ TURN SIGNAL LIGHT
RIGHT HEADLIGHT
SECONDARY GEAR SHAFT SENSOR SHIELD (2) OR MAINSHAFT SPEED SENSOR SHIELD (3, 4)
SENSOR 1
SENSOR 2
SERVICE CHECK CONNECTOR (PARTIAL)
STEERING PUMP BRACKET
TDC/CKP/CYP SENSOR SHIELD
TRANSMISSION
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION CONTROL MODULE (TCM) (A/T: CVT)
US MODELS
VEHICLE SPEED SENSOR (VSS)
VTEC PRESSURE SWITCH
W/M/T
WASHER FLUID LEVEL SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> STEERING PUMP BRACKET
