Honda Civic GA (1998-2002) door open input Wiring diagrams
This page contains all the electrical diagrams for the component. door open input, in which he is found in the car Honda Civic GA (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
door open input wiring diagram (1 of 2)
1996-98 SEDAN W/O MOONROOF
1996-98 USA: CX, DX, CANADA
1996-98 USA: LX, EX,, HX
1998 GX
1999-00
ANTI-THEFT SYSTEM (OPTIONAL)
BLK WIRE
BLU/BLK WIRE
CEILING LIGHT
COUPE, SEDAN
DOOR LOCKS SYSTEM
DOOR ON
DOOR OPEN INPUT
DRIVER'S DOOR SWITCH
EXCEPT 1996-98 SEDAN W/O MOONROOF
GRN WIRE
HATCHBACK
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INTEGRATED CONTROL UNIT
INTERIOR LIGHTS FUSE 43
KEYLESS DOOR LOCK CONTROL UNIT DOOR OPEN OUTPUT
LEFT REAR DOOR SWITCH (SEDAN)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NOT USED
OFF
PASS- ENGER'S DOOR SWITCH
RED WIRE
RIGHT REAR DOOR SWITCH (SEDAN)
SEDAN
SPOTLIGHTS
STEREO RADIO TUNER KEYLESS RECEIVER UNIT DOOR OPEN OUTPUT
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX
W/ SPOTLIGHTS
WHT/RED WIRE
Go to component -> Courtesy lamps circuit -> DOOR OPEN INPUT
door open input wiring diagram (2 of 2)
