Car Wiring Diagrams for Courtesy lamps circuit for Honda Civic Type R XI (2021-2024)

AMBIENT LIGHT (LED) BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE CARGO AREA LIGHT (HATCHBACK) CEILING LIGHT COMPUTER DATA LINES SYSTEM CURRENT CURRENT REGULATOR DRIVER'S DOOR LATCH DRIVER'S VANITY MIRROR LIGHT FRONT INDIVIDUAL MAP LIGHT FRONT PASSENGER'S DOOR LATCH FUSE 33 FUSE HOLDER A GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES INTERIOR LIGHT SWITCH LIGHT (LED) LEFT REAR DOOR LATCH LT BLU WIRE LT GRN WIRE MAP LIGHT SWITCH LIGHT (LED) OFF ON DOOR OPTIONAL CONNECTOR (HAC) PASSENGER'S VANITY MIRROR LIGHT PNK WIRE RED WIRE REGULATOR REGULATOR CURRENT (SEDAN) CONTROL UNIT (HATCHBACK) RIGHT REAR DOOR LATCH SEDAN TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE CENTER CONSOLE LIGHT CENTER JUNCTION BOX G COMPUTER DATA LINES SYSTEM DASHBOARD WIRE HARNESS JUNCTION BOX E DASHBOARD WIRE HARNESS JUNCTION BOX G DRIVER'S JUNCTION BOX A (SEDAN) DRIVER'S JUNCTION BOX B FUSE 19 FUSE 4-7 FUSE 5-4 FUSE CD FUSE HOLDER A FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GLOVE BOX LIGHT GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES ILLUMINATION CONTROL KEYLESS ACCESS SYSTEM INDICATOR LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE RELAY 1 ENERGIZED RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX RELAY ENERGIZED (HATCHBACK) HOT W/ DC-DC SEDAN TAILGATE LATCH (CENTER OF TAILGATE) TRANSCEIVER/ TRUNK LID LATCH TRUNK LIGHT UNDER-HOOD FUSE/RELAY BOX WHT WIRE
