Honda Civic Type R XI (2021-2024) Computer data lines circuit, hatchback

AUTOMATIC LIGHTING CONTROL UNIT-SENSOR BLK WIRE BLU WIRE CLIMATE CONTROL UNIT DASHBOARD WIRE HARNESS JUNCTION BOX A DASHBOARD WIRE HARNESS JUNCTION BOX G DATA LINK CONNECTOR (DLC) FRONT SEAT HEATER CONTROL UNIT FUSE 19 FUSE HOLDER A HOT AT ALL TIMES LEFT HEADLIGHT LEFT SIDE BSI RADAR UNIT LT BLU WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RED WIRE RELAY CONTROL MODULE RIGHT END OF DASH) RIGHT HEADLIGHT RIGHT SIDE BSI RADAR UNIT TAN WIRE THERMAL JOINT 10 THERMAL JOINT 11 UNDER-HOOD FUSE/RELAY BOX WHT WIRE WIRELESS CHARGER YEL WIRE

AUDIO UNIT BLK WIRE BLU WIRE BODY CONTROL MODULE (LEFT END OF DASH) BRN WIRE DASHBOARD WIRE HARNESS JUNCTION BOX C FUSE 11 FUSE 25 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LT BLU WIRE LT GRN WIRE MULTIPURPOSE CAMERA UNIT PARKING, BACKUP SENSOR CONTROL UNIT PNK WIRE PPL RED WIRE TAN WIRE UNDER- DASH FUSE/ RELAY BOX WHT WIRE YEL WIRE

12 VOLT BATTERY SENSOR 2.0L ALTERNATOR AUDIO REMOTE- HFL SWITCH AUTOMATIC LIGHTING/ RAIN SENSOR BLU WIRE CABLE REEL DASHBOARD WIRE HARNESS JUNCTION BOX K DC-DC CONVERTER GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE M/T PNK CVT PNK WIRE PNK WIRE PPL RED WIRE W/ AUTOMATIC LIGHTING/RAIN SENSOR W/O AUTOMATIC LIGHTING/RAIN SENSOR WHT WIRE WINDSHIELD WIPER CONTROL UNIT/MOTOR YEL WIRE

2.0L BLU WIRE BRN WIRE CVT DASHBOARD WIRE HARNESS JUNCTION BOX B ELECTRIC OIL PUMP ELECTRIC VACUUM PUMP CONTROL UNIT EPS CONTROL UNIT GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE M/T PNK WIRE PPL RED WIRE SRS UNIT TRANSMISSION CONTROL MODULE VSA MODULATOR CONTROL UNIT WHT WIRE YEL WIRE
