Honda Civic Type R XI (2021-2024) turbocharger boost sensor Wiring diagram

This page shows the only wiring diagram for the component.turbocharger boost sensor, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram turbocharger boost sensor (1 of 1)

Wiring diagram turbocharger boost sensor for Honda Civic Type R XI (2021-2024)

Get access

BLK WIRE BRN WIRE ENGINE OIL PRESSURE SENSOR GRN WIRE GRY WIRE HATCHBACK ICM IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LT BLU WIRE PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/TAN WIRE PPL/WHT WIRE RED WIRE SEDAN SPARK PLUG TAN WIRE THERMAL JOINT 3 TURBOCHARGER TURBOCHARGER BOOST SENSOR TURBOCHARGER WASTEGATE CONTROL ACTUATOR TURBOCHARGER WASTEGATE CONTROL ACTUATOR POSITION SENSOR WHT WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 1.5l turbo (6 of 8) -> TURBOCHARGER BOOST SENSOR
