Honda Civic Type R XI (2021-2024) touring except touring Wiring diagram
This page shows the only wiring diagram for the component.touring except touring, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram touring except touring (1 of 1)
A/F SENSOR (SENSOR 1) SHIELD
BLK WIRE
BRN WIRE
HIGH PRESSURE FUEL PUMP SHIELD
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
KEYLESS BUZZER
KNOCK SENSOR SHIELD
LEFT BACKUP LIGHT
LEFT INNER TAILLIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE BSI RADAR UNIT
LEFT TAILLIGHT
LICENSE PLATE LIGHT
PARKING, BACKUP SENSOR CONTROL UNIT
PCM
RIGHT BACKUP LIGHT
RIGHT INNER TAILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE BSI RADAR UNIT
RIGHT TAILLIGHT
ROCKER ARM OIL CONTROL SOLENOID
THERMAL JOINT 1
THERMAL JOINT 2
THERMAL JOINT 3
THERMAL JOINT 4
TOURING EXCEPT TOURING
TURN LID LATCH
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
Go to component -> Ground distribution circuit, sedan (1 of 4) -> TOURING EXCEPT TOURING
