Honda Civic Type R XI (2021-2024) thermal joint 10 Wiring diagram
This page shows the only wiring diagram for the component.thermal joint 10, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thermal joint 10 (1 of 1)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BLU WIRE
CLIMATE CONTROL UNIT
DASHBOARD WIRE HARNESS JUNCTION BOX A
DASHBOARD WIRE HARNESS JUNCTION BOX G
DATA LINK CONNECTOR (DLC)
FRONT SEAT HEATER CONTROL UNIT
FUSE 19
FUSE HOLDER A
HOT AT ALL TIMES
LEFT HEADLIGHT
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY CONTROL MODULE
RIGHT END OF DASH)
RIGHT HEADLIGHT
RIGHT SIDE BSI RADAR UNIT
TAN WIRE
THERMAL JOINT 10
THERMAL JOINT 11
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component: -> Computer data lines circuit, hatchback (1 of 4) -> THERMAL JOINT 10
