Honda Civic Type R XI (2021-2024) relay control module under-hood fuse/relay box Wiring diagrams

This page contains all the electrical diagrams for the component. relay control module under-hood fuse/relay box, in which he is found in the car Honda Civic Type R XI (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram relay control module under-hood fuse/relay box (1 of 3)

Wiring diagram relay control module under-hood fuse/relay box for Honda Civic Type R XI (2021-2024)

Get access

B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE CENTER CONSOLE LIGHT CENTER JUNCTION BOX G COMPUTER DATA LINES SYSTEM DASHBOARD WIRE HARNESS JUNCTION BOX E DASHBOARD WIRE HARNESS JUNCTION BOX G DRIVER'S JUNCTION BOX A (SEDAN) DRIVER'S JUNCTION BOX B FUSE 19 FUSE 4-7 FUSE 5-4 FUSE CD FUSE HOLDER A FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GLOVE BOX LIGHT GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES ILLUMINATION CONTROL KEYLESS ACCESS SYSTEM INDICATOR LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE RELAY 1 ENERGIZED RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX RELAY ENERGIZED (HATCHBACK) HOT W/ DC-DC SEDAN TAILGATE LATCH (CENTER OF TAILGATE) TRANSCEIVER/ TRUNK LID LATCH TRUNK LIGHT UNDER-HOOD FUSE/RELAY BOX WHT WIRE

Go to component: -> Courtesy lamps circuit (2 of 2) -> RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX

Wiring diagram relay control module under-hood fuse/relay box (2 of 3)

Wiring diagram relay control module under-hood fuse/relay box for Honda Civic Type R XI (2021-2024)

Get access

B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX G COMPUTER DATA LINES SYSTEM DASHBOARD WIRE HARNESS JUNCTION BOX G DOOR MULTIPLEX CONTROL UNIT DRIVER'S JUNCTION BOX A DRIVER'S JUNCTION BOX B FUSE 19 FUSE 4-7 FUSE 5-4 FUSE CD FUSE HOLDER A FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES ILLUMINATION CONTROL KEYLESS ACCESS SYSTEM INDICATOR LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE PNK WIRE POWER WINDOW MASTER SWITCH RED WIRE RELAY 1 ENERGIZED RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX RELAY ENERGIZED (HATCHBACK) HOT W/ DC-DC SEDAN TAILGATE LATCH (CENTER OF TAILGATE) TRANSCEIVER/ TRUNK LID LATCH TRUNK LIGHT UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component: -> Entry light timer circuit (2 of 2) -> RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX

Wiring diagram relay control module under-hood fuse/relay box (3 of 3)

Wiring diagram relay control module under-hood fuse/relay box for Honda Civic Type R XI (2021-2024)

Get access

BLK WIRE CABLE REEL FUSE 18 FUSE HOLDER A FUSE/RELAY HOLDER D GRN WIRE HORN (HIGH) HORN (LOW) HORN RELAY HORN SWITCH HOT AT ALL TIMES LT GRN WIRE PNK WIRE PPL RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX SEDAN HATCHBACK TAN WIRE UNDER-HOOD FUSE/RELAY BOX W/ DUAL HORN WHT WIRE

Go to component: -> Horn circuit -> RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX
