Honda Civic Type R XI (2021-2024) ppl cooling fans system Wiring diagram
This page shows the only wiring diagram for the component.ppl cooling fans system, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl cooling fans system (1 of 1)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
DASHBOARD WIRE HARNESS JUNCTION BOX D
EVAP CANISTER VENT SHUT VALVE
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
GAUGE CONTROL MODULE
GRN WIRE
HATCHBACK
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
LOW OIL PRESSURE INDICATOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL COOLING FANS SYSTEM
PPL/BLK WIRE
PPL/BLU WIRE
SEDAN
TAN WIRE
THERMAL JOINT 2 (SEDAN) THERMAL JOINT 1 (HATCHBACK)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo (3 of 8) -> PPL COOLING FANS SYSTEM
