Honda Civic Type R XI (2021-2024) left rear seat cushion heater Wiring diagram
This page shows the only wiring diagram for the component.left rear seat cushion heater, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat cushion heater (1 of 1)
BLK WIRE
BLU WIRE
BREAKER
BRN WIRE
CENTER JUNCTION BOX A
DASHBOARD WIRE HARNESS JUNCTION BOX A
FUSE 43
GRN WIRE
GRY WIRE
HATCHBACK
HIGH INDICATOR
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT REAR SEAT CUSHION HEATER
LOW INDICATOR
LT BLU WIRE
LT GRN WIRE
MIDDLE INDICATOR
PNK WIRE
PPL
REAR SEAT HEATER RELAY
RED WIRE
RIGHT REAR SEAT CUSHION HEATER
RIGHT REAR SEAT HEATER SWITCH
SEDAN
THERMISTOR
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
Go to component: -> Rear heated seats circuit (2 of 2) -> LEFT REAR SEAT CUSHION HEATER
