Honda Civic Type R XI (2021-2024) left rear seat belt tensioner Wiring diagram

This page shows the only wiring diagram for the component.left rear seat belt tensioner, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left rear seat belt tensioner (1 of 1)

Wiring diagram left rear seat belt tensioner for Honda Civic Type R XI (2021-2024)

Get access

BLU WIRE DRIVER'S SEAT BELT TENSIONER DRIVER'S SIDE AIR BAG DRIVER'S SIDE AIR BAG INFLATOR FRONT PASSENGER'S SIDE AIR BAG FRONT PASSENGER'S SIDE AIR BAG INFLATOR GRN WIRE GRY WIRE HATCHBACK LEFT "C" PILLAR) LEFT REAR SEAT BELT TENSIONER LEFT REAR SIDE AIR BAG LEFT REAR SIDE AIR BAG INFLATOR LEFT SIDE IMPACT SENSOR (FIRST) LEFT SIDE IMPACT SENSOR (SECOND) LT BLU WIRE LT GRN WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RIGHT SIDE CURTAIN AIR BAG RIGHT SIDE CURTAIN AIR BAG INFLATOR RIGHT SIDE IMPACT SENSOR (FIRST) SEDAN SEDAN HATCHBACK SELECTABLE ENERGY ABSORPTION DEVICE SRS UNIT WHT WIRE YEL WIRE

Go to component: -> Supplemental restraints circuit (4 of 4) -> LEFT REAR SEAT BELT TENSIONER
