Honda Civic Type R XI (2021-2024) left inner tailgate Wiring diagram
This page shows the only wiring diagram for the component.left inner tailgate, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left inner tailgate (1 of 1)
2.0L
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER ACC RELAY
DRIVER'S VANITY MIRROR LIGHT
ECON REAR WINDOW WIPER MOTOR
FRONT ACCESSORY POWER SOCKET RELAY
FRONT INDIVIDUAL MAP LIGHT
FRONT SEAT HEATER RELAY
FUSE/RELAY HOLDER A
GRN WIRE
GRY WIRE
HIGH MOUNT BRAKE LIGHT
LEFT "C" PILLAR)
LEFT BACKUP LIGHT
LEFT INNER TAILGATE
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
LICENSE PLATE LIGHT/TAILGATE OUTER HANDLE SWITCH/ LOCK SWITCH
MOONROOF MOTOR/ CONTROL UNIT
MOONROOF SWITCH
MULTIPURPOSE CAMERA UNIT
PARKING, BACKUP SENSOR SWITCH/ SAFETY SUPPORT SWITCH
PASSENGER'S VANITY MIRROR LIGHT
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER WINDOW MASTER SWITCH
REAR SEAT HEATER CONTROL UNIT
REAR SEAT HEATER RELAY
REAR VIEW MIRROR)
REAR WINDOW DEFOGGER
RED WIRE
RIGHT BACKUP LIGHT
RIGHT INNER TAILGATE
TAILGATE LATCH
TAILGATE RELEASE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
YEL WIRE
Go to component: -> Ground distribution circuit, hatchback (4 of 4) -> LEFT INNER TAILGATE
