Honda Civic Type R XI (2021-2024) fuse 40 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 40, in which he is found in the car Honda Civic Type R XI (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 40 (1 of 4)
BACKWARD
BLK WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR
DRIVER'S POWER SEAT RECLINE MOTOR
DRIVER'S POWER SEAT SLIDE MOTOR
DRIVER'S POWER SEAT UP-DOWN MOTOR
FORWARD/
FRONT UP-DOWN SWITCH
FUSE 40
FUSE 41
GRN WIRE
GRY WIRE
HATCHBACK
HOT AT ALL TIMES
LT BLU WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR UP-DOWN SWITCH
RECLINE SWITCH
RED WIRE
SEDAN
SLIDE SWITCH
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> FUSE 40
Wiring diagram fuse 40 (2 of 4)
AUDIO REMOTE- HFL SWITCH
BLU WIRE
BRN WIRE
CABLE REEL
CAN GATEWAY
DASHBOARD WIRE HARNESS JUNCTION BOX J
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH
EPS CONTROL UNIT
FROM FUSE 9 (DIAGRAM 5 OF 6)
FROM FUSE HOLDER A (DIAGRAM 1 OF 6)
FROM FUSE HOLDER A (DIAGRAM 2 OF 6)
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER RELAY
FUSE 1
FUSE 10
FUSE 16
FUSE 2
FUSE 22
FUSE 25
FUSE 26
FUSE 28
FUSE 40
FUSE 41
FUSE 48
FUSE 49
FUSE 52
FUSE 53
FUSE 54
FUSE 55
GRN WIRE
LT BLU WIRE
MOONROOF CONTROL UNIT/MOTOR
PNK WIRE
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK/UNLOCK)
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
REAR SEAT HEATER RELAY
RED WIRE
SRS UNIT
STEREO AMPLIFIER
TAILGATE RELEASE ACTUATOR RELAY
TO DASHBOARD WIRE HARNESS JUNCTION BOX J (DIAGRAM 5 OF 6)
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hatchback (3 of 6) -> FUSE 40
Wiring diagram fuse 40 (3 of 4)
A/C COMPRESSOR CLUTCH RELAY
AUDIO REMOTE- HFL SWITCH
AUDIO UNIT
BLOWER MOTOR RELAY
BLU WIRE
BRN WIRE
CABLE REEL
CENTER JUNCTION BOX A
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
DRIVER'S JUNCTION BOX A
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH
FROM FUSE C (DIAGRAM 6 OF 6)
FROM FUSE HOLDER A (DIAGRAM 2 OF 6)
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT SEAT HEATER RELAY
FUSE 34
FUSE 37
FUSE 40
FUSE 41
FUSE 43
FUSE 48
FUSE 49
FUSE 53
FUSE 54
FUSE A
FUSE B (+)
FUSE/RELAY HOLDER A
FUSE/RELAY HOLDER B
FUSE/RELAY HOLDER D
FUSE/RELAY HOLDER F
GRN WIRE
LT BLU WIRE
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY FUSE/RELAY HOLDER B
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, sedan (4 of 6) -> FUSE 40
Wiring diagram fuse 40 (4 of 4)
Go to component -> Wiring diagram engine performance 1.5l turbo (2 of 8) -> FUSE 40
