Honda Civic Type R XI (2021-2024) front up-down switch Wiring diagram

This page shows the only wiring diagram for the component.front up-down switch, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front up-down switch (1 of 1)

Wiring diagram front up-down switch for Honda Civic Type R XI (2021-2024)

Get access

BACKWARD BLK WIRE BRN WIRE DOWN DRIVER'S POWER SEAT ADJUSTMENT SWITCH DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR DRIVER'S POWER SEAT RECLINE MOTOR DRIVER'S POWER SEAT SLIDE MOTOR DRIVER'S POWER SEAT UP-DOWN MOTOR FORWARD/ FRONT UP-DOWN SWITCH FUSE 40 FUSE 41 GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES LT BLU WIRE ORG/ WIRE PNK WIRE PPL REAR UP-DOWN SWITCH RECLINE SWITCH RED WIRE SEDAN SLIDE SWITCH UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component: -> Driver power seat circuit -> FRONT UP-DOWN SWITCH
