Honda Civic Type R XI (2021-2024) front seat heater control unit Wiring diagrams
This page contains all the electrical diagrams for the component. front seat heater control unit, in which he is found in the car Honda Civic Type R XI (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front seat heater control unit (1 of 8)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BLU WIRE
CLIMATE CONTROL UNIT
DASHBOARD WIRE HARNESS JUNCTION BOX A
DASHBOARD WIRE HARNESS JUNCTION BOX G
DATA LINK CONNECTOR (DLC)
FRONT SEAT HEATER CONTROL UNIT
FUSE 19
FUSE HOLDER A
HOT AT ALL TIMES
LEFT HEADLIGHT
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY CONTROL MODULE
RIGHT END OF DASH)
RIGHT HEADLIGHT
RIGHT SIDE BSI RADAR UNIT
TAN WIRE
THERMAL JOINT 10
THERMAL JOINT 11
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component: -> Computer data lines circuit, hatchback (1 of 4) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (2 of 8)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX A
CLIMATE CONTROL UNIT
DATA LINK CONNECTOR (DLC)
DRIVER'S JUNCTION BOX B
FRONT SEAT HEATER CONTROL UNIT
FUSE 19
FUSE HOLDER A
GRY WIRE
HOT AT ALL TIMES
LEFT HEADLIGHT
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
OPTION CONNECTOR (HAC)
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY CONTROL MODULE
RIGHT END OF DASH)
RIGHT HEADLIGHT
RIGHT SIDE BSI RADAR UNIT
TAN WIRE
THERMAL JOINT 7
THERMAL JOINT 8
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component: -> Computer data lines circuit, sedan (1 of 4) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (3 of 8)
BLK WIRE
BLU WIRE
BREAKER
CENTER JUNCTION BOX A
CENTER JUNCTION BOX E
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DASHBOARD WIRE HARNESS JUNCTION BOX A
DASHBOARD WIRE HARNESS JUNCTION BOX D
DRIVER'S SEAT CUSHION HEATER (SEDAN)
DRIVER'S SEAT- BACK HEATER
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER RELAY
FUSE 43
FUSE 48
FUSE CD
FUSE/RELAY HOLDER A
GRN WIRE
GRY WIRE
HATCHBACK
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
LT BLU WIRE
LT GRN WIRE
PPL
RED WIRE
RIGHT END OF DASH)
SEDAN
TAN WIRE
THERMISTOR
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component: -> Front heated seats circuit (1 of 2) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (4 of 8)
12 VOLT BATTERY SENSOR
A/C CONDENSER FAN MOTOR
AUDIO REMOTE- HFL SWITCH
AUDIO REMOTE- HLF SWITCH
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BODY CONTROL MODULE
CABLE REEL
CAN GATEWAY
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
DRIVER'S DOOR LATCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MOTOR
ELECTRIC STEERING LOCK
ENGINE START/ STOP SWITCH
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER CONTROL UNIT
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH
HOOD LATCH SWITCH
HORN (HIGH)
HORN (LOW)
KEY BUZZER
LEFT POWER MIRROR
LEFT SIDE BSI RADAR UNIT
PARKING, BACKUP SENSOR CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RIGHT POWER MIRROR
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE BSI RADAR UNIT
STEERING HEATER
Go to component: -> Ground distribution circuit, hatchback (2 of 4) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (5 of 8)
2.0L
A/C CONDENSER FAN MOTOR
ACTIVE SOUND CONTROL UNIT
AUDIO REMOTE- HFL SWITCH
AUTOMATIC DIMMING INSIDE MIRROR/ HOMELINK UNIT
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BODY CONTROL MODULE
CABLE REEL
CAN GATEWAY
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER ACC RELAY
DRIVER'S DOOR LATCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MOTOR
DRIVER'S VANITY MIRROR LIGHT
ELECTRIC STEERING LOCK
ENGINE START/ STOP SWITCH
FRONT ACCESSORY POWER SOCKET RELAY
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER RELAY
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH
HOOD LATCH SWITCH
HORN (HIGH)
LEFT POWER MIRROR
MOONROOF MOTOR/ CONTROL UNIT
MULTIPURPOSE CAMERA UNIT
PARKING, BACKUP SENSOR/ SAFETY SUPPORT SWITCH
PASSENGER'S VANITY MIRROR LIGHTS
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER
RIGHT POWER MIRROR
ROOF MODULE)
TRUNK LID OPENER SWITCH
TRUNK LID RELEASE ACTUATOR RELAY
VSA OFF/ SAFETY SUPPORT SWITCH
Go to component: -> Ground distribution circuit, sedan (2 of 4) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (6 of 8)
2.0L
AUDIO ACC DIODE
AUDIO UNIT
BACKUP LIGHT SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CAN GATEWAY
COMPUTER DATA LINES SYSTEM
DASHBOARD WIRE HARNESS JUNCTION BOX B
DASHBOARD WIRE HARNESS JUNCTION BOX C
DASHBOARD WIRE HARNESS JUNCTION BOX D
DC-DC CONVERTER (LEFT SIDE OF DASH)
DC-DC CONVERTER ACC RELAY
ELECTRIC OIL PUMP RELAY
FROM DASHBOARD WIRE HARNESS JUNCTION BOX G (DIAGRAM 2 OF 6)
FROM FUSE HOLDER A (DIAGRAM 1 OF 6)
FROM FUSE HOLDER A (DIAGRAM 2 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
FRONT SEAT HEATER CONTROL UNIT
FUSE 36
FUSE C
FUSE D
FUSE E
FUSE F
FUSE H
FUSE/ RELAY HOLDER E
FUSE/RELAY HOLDER A
FUSE/RELAY HOLDER D
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
LEFT REAR SEAT HEATER SWITCH
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
LT GRN WIRE
MULTIPURPOSE CAMERA UNIT
PARKING, BACKUP SENSOR CONTROL UNIT
PARKING, BACKUP SENSOR SWITCH/SAFETY SUPPORT SWITCH
PCM
PNK WIRE
PPL
RED WIRE
REVERSE LOCKOUT SOLENOID
RIGHT REAR SEAT HEATER SWITCH
RIGHT SIDE BSI RADAR UNIT
SHIFT LOCK SOLENOID
SHIFT POSITION INDICATOR PANEL
TAN WIRE
TO FUSE A (DIAGRAM 4 OF 6)
TURBOCHARGER BYPASS CONTROL SOLENOID VALVE
UNDER-HOOD FUSE/RELAY BOX
USB CHARGER UNIT
W/ AMPLIFIER
W/O AMPLIFIER
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component: -> Power distribution circuit, hatchback (6 of 6) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (7 of 8)
ACTIVE SOUND CONTROL UNIT
AUDIO ACC DIODE
AUDIO UNIT
BACKUP LIGHT SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CAN GATEWAY
CENTER JUNCTION BOX D
CENTER JUNCTION BOX E
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER (DRIVER'S DOOR)
DC-DC CONVERTER ACC RELAY
ELECTRIC OIL PUMP RELAY
FROM DRIVER'S JUNCTION BOX B (DIAGRAM 2 OF 6)
FROM FUSE HOLDER A (DIAGRAM 1 OF 6)
FROM FUSE HOLDER A (DIAGRAM 2 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
FRONT SEAT HEATER CONTROL UNIT
FUSE 36
FUSE C
FUSE D
FUSE E
FUSE F
FUSE H
FUSE/ RELAY HOLDER E
FUSE/RELAY HOLDER D
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
LT GRN WIRE
MULTIPURPOSE CAMERA UNIT
PARKING, BACKUP SENSOR CONTROL UNIT
PARKING, BACKUP SENSOR SWITCH/SAFETY SUPPORT SWITCH
PCM
PNK WIRE
PPL
RED WIRE
REVERSE LOCKOUT SOLENOID
RIGHT SIDE BSI RADAR UNIT
SHIFT POSITION INDICATOR PANEL
TAN WIRE
TO FUSE A (DIAGRAM 4 OF 6)
TOP OF TRANSMISSION)
TURBOCHARGER BYPASS CONTROL SOLENOID VALVE
UNDER-HOOD FUSE/RELAY BOX
USB CHARGER
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component: -> Power distribution circuit, sedan (6 of 6) -> FRONT SEAT HEATER CONTROL UNIT
Wiring diagram front seat heater control unit (8 of 8)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX E
DASHBOARD WIRE HARNESS JUNCTION BOX D
FRONT SEAT HEATER CONTROL UNIT
FUSE 11
FUSE 52
FUSE CD
FUSE/RELAY HOLDER A
GRN WIRE
GRY WIRE
HATCHBACK
HIGH INDICATOR
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
LEFT "C" PILLAR)
LEFT REAR SEAT HEATER SWITCH
LOW INDICATOR
LT BLU WIRE
LT GRN WIRE
MIDDLE INDICATOR
PNK WIRE
PPL
REAR SEAT HEATER CONTROL UNIT
RED WIRE
SEDAN
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component: -> Rear heated seats circuit (1 of 2) -> FRONT SEAT HEATER CONTROL UNIT
