Honda Civic Type R XI (2021-2024) driver's seat belt outer lap tensioner Wiring diagram

This page shows the only wiring diagram for the component.driver's seat belt outer lap tensioner, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver's seat belt outer lap tensioner (1 of 1)

Wiring diagram driver's seat belt outer lap tensioner for Honda Civic Type R XI (2021-2024)

Get access

BLK WIRE BLU WIRE CENTER/RIGHT REAR SEAT BELT BUCKLE SWITCH DRIVER'S SEAT BELT BUCKLE SWITCH DRIVER'S SEAT BELT OUTER LAP TENSIONER FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FRONT PASSENGER'S SEAT BELT OUTER LAP TENSIONER GRN WIRE GRY WIRE HATCHBACK LEFT REAR SEAT BELT BUCKLE SWITCH LEFT SIDE CURTAIN AIR BAG LEFT SIDE CURTAIN AIR BAG INFLATOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT RIGHT REAR SEAT BELT TENSIONER RIGHT REAR SIDE AIR BAG RIGHT REAR SIDE AIR BAG INFLATOR RIGHT SIDE IMPACT SENSOR (SECOND) SEDAN SEDAN HATCHBACK WHT WIRE YEL WIRE

Go to component: -> Supplemental restraints circuit (3 of 4) -> DRIVER'S SEAT BELT OUTER LAP TENSIONER
