Honda Civic Type R XI (2021-2024) driver mode/idle stop off switch Wiring diagram
This page shows the only wiring diagram for the component.driver mode/idle stop off switch, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver mode/idle stop off switch (1 of 1)
BLU WIRE
CLIMATE CONTROL SWITCH
CRUSIE CONTROL/ ACC COMBINATION SWITCH
DASH LIGHT BRIGHTNESS CONTROL SWITCH
DRIVER MODE/IDLE STOP OFF SWITCH
ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH
FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HOT AT ALL TIMES
LT BLU WIRE
RED WIRE
RIGHT END OF DASH)
ROOF MODULE)
SHIFT POSITION INDICATOR
SRS UNIT
THERMAL JOINT 5
THERMAL JOINT 6
UNDER-DASH FUSE/RELAY BOX
USB PORT HOLDER
VSA OFF SWITCH/ SAFETY SUPPORT SWITCH
WHT WIRE
Go to component: -> Instrument illumination circuit, sedan (2 of 2) -> DRIVER MODE/IDLE STOP OFF SWITCH
