Honda Civic Type R XI (2021-2024) brake system ind Wiring diagrams

This page contains all the electrical diagrams for the component. brake system ind, in which he is found in the car Honda Civic Type R XI (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram brake system ind (1 of 3)

Wiring diagram brake system ind for Honda Civic Type R XI (2021-2024)

Get access

AUDIO REMOTE- HFL SWITCH BLK WIRE BLU WIRE BRAKE SYSTEM IND BRN WIRE CANCEL SWITCH COMPUTER DATA LINES SYSTEM CRUISE CONTROL/ ACC COMBINATION SWITCH DASHBOARD WIRE HARNESS JUNCTION BOX D DISTANCE SWITCH F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE D FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GRN WIRE HOT W/ DC-DC LKAS SWITCH LT BLU WIRE LT GRN WIRE MAIN SWITCH PNK WIRE PPL RED WIRE RELAY ENERGIZED RES/+ SWITCH SET SWITCH TAN WIRE WHT WIRE YEL WIRE

Go to component: -> Cruise control circuit, hatchback (3 of 3) -> BRAKE SYSTEM IND

Wiring diagram brake system ind (2 of 3)

Wiring diagram brake system ind for Honda Civic Type R XI (2021-2024)

Get access

BLK WIRE BLU WIRE BRAKE SYSTEM IND CANCEL SWITCH CENTER JUNCTION BOX E COMPUTER DATA LINES SYSTEM CRUISE CONTROL/ ACC COMBINATION SWITCH DISTANCE SWITCH F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE D FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GRN WIRE HOT W/ DC-DC LKAS SWITCH LT BLU WIRE LT GRN WIRE MAIN SWITCH RED WIRE RELAY ENERGIZED RES/+ SWITCH SET SWITCH TAN WIRE WHT WIRE YEL WIRE

Go to component: -> Cruise control circuit, sedan (3 of 3) -> BRAKE SYSTEM IND

Wiring diagram brake system ind (3 of 3)

Wiring diagram brake system ind for Honda Civic Type R XI (2021-2024)

Get access

12 VOLT CHARGING SYSTEM IND ABS IND. ANTI-LOCK BRAKES SYSTEM AUTOMATIC BRAKE HOLD IND AUTOMATIC BRAKE HOLD SYSTEM IND B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRAKE SYSTEM IND BRAKE SYSTEM IND (AMBER) BRAKE SYSTEM IND (RED) WIRE BRN WIRE CENTER JUNCTION BOX E COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DASHBOARD WIRE HARNESS JUNCTION BOX B DASHBOARD WIRE HARNESS JUNCTION BOX G DRIVE MODE SWITCH DRIVER'S JUNCTION BOX B ECON SWITCH EPS IND F-CAN H F-CAN L F-CAN TRANSCEIVER FRONT FOG LIGHT IND FUEL GAUGE SENDING UNIT FUEL TANK UNIT FUSE 19 FUSE 24 FUSE 5-5 FUSE CD FUSE HOLDER A FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GRN WIRE HATCHBACK HATCHBACK 1.5L TURBO, SEDAN 1.5L TURBO CVT HATCHBACK CVT HIGH BEAM IND HOT AT ALL TIMES IDLE STOP OFF SWITCH IDLE STOP OFF SWITCH/ ECON SWITCH (HATCHBACK CVT) IMMOBILIZER/ SECURITY IND KEYLESS ACCESS SYSTEM IND LEFT TURN SIGNAL IND LIGHTS ON IND LOW OIL PRESSURE IND LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL/RED WIRE RED WIRE RELAY 1 ENERGIZED RELAY ENERGIZED (HATCHBACK) HOT W/ DC-DC RIGHT TURN SIGNAL IND SEAT BELT REMINDER IND (LED) SEDAN SEDAN 1.5 TUBO M/T, 2.0L, HATCHBACK 2.0L SEDAN, HATCHBACK M/T SRS IND (RED) (LED) WIRE TAN WIRE UNDER-HOOD FUSE/RELAY BOX VSA IND VSA OFF IND WHT WIRE WIPER/WASHER SYSTEM YEL WIRE

Go to component: -> Instrument cluster circuit (1 of 3) -> BRAKE SYSTEM IND
