Honda Civic Type R XI (2021-2024) automatic brake Wiring diagram
This page shows the only wiring diagram for the component.automatic brake, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic brake (1 of 1)
ABS IND.
AUTOMATIC BRAKE
BLK WIRE
BLU WIRE
BRAKE BOOSTER PRESSURE SENSOR 1
BRAKE BOOSTER PRESSURE SENSOR 2
BRAKE FLUID LEVEL SWITCH
BRAKE/
BRN WIRE
CENTER JUNCTION BOX E
CLUTCH PEDAL STROKE SENSOR
COMPUTER DATA LINES SYSTEM
ELECTRIC VACUUM PUMP CONTROL UNIT
ELECTRIC VACUUM PUMP MOTOR
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE D
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOLD IND
HOLD SYSTEM IND
HOT W/ DC-DC
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
SYSTEM IND
VSA IND
VSA OFF IND
VSA OFF/SAFETY SUPPORT SWITCH
WHT WIRE
YEL WIRE
Go to component: -> Anti-lock brakes circuit, sedan (3 of 3) -> AUTOMATIC BRAKE
