Honda Civic Type R XI (2021-2024) auto auto open close Wiring diagram
This page shows the only wiring diagram for the component.auto auto open close, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto auto open close (1 of 1)
AUTO AUTO CLOSE OPEN
AUTO AUTO OPEN CLOSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
CENTER JUNCTION BOX E
CLOSE RELAY
COMPUTER DATA LINES SYSTEM
DASHBOARD WIRE HARNESS JUNCTION BOX D
DOOR MULTIPLEX CONTROL UNIT POWER WINDOW MASTER SWITCH
FUSE 16
GRN WIRE
GRY WIRE
HALL SENSOR
HATCHBACK
HOT AT ALL TIMES
MOONROOF CONTROL UNIT (RIGHT FRONT OF ROOF)
MOTOR
OFF OPEN CLOSE
OPEN RELAY
PNK WIRE
RED WIRE
ROOF MODULE (SEDAN) MOONROOF SWITCH (HATCHBACK)
SEDAN
TAN WIRE
TILT SWITCH
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component: -> Power top/sunroof circuit -> AUTO AUTO OPEN CLOSE
