Honda Civic Type R XI (2021-2024) audio remote- hlf switch Wiring diagram
This page shows the only wiring diagram for the component.audio remote- hlf switch, which is found in the car Honda Civic Type R XI (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio remote- hlf switch (1 of 1)
12 VOLT BATTERY SENSOR
A/C CONDENSER FAN MOTOR
AUDIO REMOTE- HFL SWITCH
AUDIO REMOTE- HLF SWITCH
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BODY CONTROL MODULE
CABLE REEL
CAN GATEWAY
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
DRIVER'S DOOR LATCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MOTOR
ELECTRIC STEERING LOCK
ENGINE START/ STOP SWITCH
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER CONTROL UNIT
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH
HOOD LATCH SWITCH
HORN (HIGH)
HORN (LOW)
KEY BUZZER
LEFT POWER MIRROR
LEFT SIDE BSI RADAR UNIT
PARKING, BACKUP SENSOR CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RIGHT POWER MIRROR
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE BSI RADAR UNIT
STEERING HEATER
Go to component: -> Ground distribution circuit, hatchback (2 of 4) -> AUDIO REMOTE- HLF SWITCH
