Car Wiring Diagrams for Trunk release circuit, sedan for Honda Civic Type R X (2015-2021)

32 BIT B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BODY CONTROL MODULE CAN CONTROLLER COMPUTER DATA LINES SYSTEM DISTRIBUTION DOOR MULTIPLEX CONTROL UNIT DOOR, TRUNK LID OPEN IND DRIVER'S JUNCTION DRIVING CIRCUIT FUSE 16 FUSE 18 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MICROPROCESSOR PNK WIRE POWER POWER WINDOW MASTER SWITCH RED WIRE SEDAN COUPE W/ CAN GATEWAY, HANDSFREE LINK W/ SEGMENT SYSTEM TAN WIRE TRUNK LID LATCH TRUNK LID OPENER SWITCH TRUNK LID OUTER HANDLE SWITCH/LICENSE PLATE LIGHT TRUNK LID RELEASE ACTUATOR RELAY TRUNK LIGHT UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WARNING WHT WIRE
